Trunk & fuel door release circuit for Ford Thunderbird X (1988-1997)
Trunk & fuel door release circuit
BLK WIRE
BLK/WHT WIRE
FUEL FILLER DOOR RELEASE SOLENOID (RIGHT REAR OF TRUNK)
FUEL FILLER DOOR RELEASE SWITCH (RIGHT SIDE OF I/P, IN LEFT SIDE OF GLOVE BOX)
HOT AT ALL TIMES
PNK WIRE
PPL/YEL WIRE
PRIMARY JUNCTION BLOCK (BEHIND I/P, LEFT OF STEERING COLUMN)
SEAT/LOCK CIRCUIT BREAKER
TRUNK LID RELEASE OUTPUT
TRUNK LID RELEASE SOLENOID (IN RIGHT REAR OF TRUNK LID)
TRUNK LID RELEASE SWITCH
WHT WIRE
