Car Wiring Diagrams for Door lock circuit for Ford Thunderbird X (1988-1997)

BLK WIRE BLK/WHT WIRE FUSE HOT IN ACCY OR RUN HOT IN ACCY OR RUN SEAT/LOCK CIRCUIT BREAKER LEFT DOOR LOCK MOTOR LEFT DOOR LOCK SWITCH LOCK LT GRN WIRE PNK WIRE PNK/BLK WIRE PNK/ORG WIRE PPL PRIMARY JUNCTION BLOCK RIGHT DOOR LOCK MOTOR RIGHT DOOR LOCK SWITCH UNLOCK WHT WIRE WHT/PPL WIRE YEL WIRE
