Horn circuit for Ford Thunderbird X (1988-1997)
Horn circuit
BLK WIRE
BLU WIRE
CLOCKSPRING ASSEMBLY
DK BLU WIRE
FUSE 10
GRN WIRE
HIGH PITCH HORN
HORN CONTROL
HORN RELAY
HORN SWITCH
HOT AT ALL TIMES
JUNCTION CONNECTOR (ABOVE STEERING COLUMN)
LOW PITCH HORN LT
LT GRN WIRE
POWER DISTRIBUTION BOX (LEFT SIDE OF ENGINE COMPARTMENT)
REMOTE KEYLESS ENTRY MODULE (LEFT SIDE OF TRUNK)
SECONDARY JUNCTION BLOCK (RIGHT SIDE OF STEERING COLUMN)
SPEED CONTROL SWITCH ASSEMBLY SLIP RING
YEL WIRE
