Headlamps/fog lamps circuit, without drl for Ford Thunderbird X (1988-1997)
Headlamps/fog lamps circuit, without drl
BLK WIRE
CIGAR LTR FUSE
DK BLU/ORG WIRE
FLASH-TO-PASS SWITCH DIMMER SWITCH
FOG FUSE
FOG LIGHT RELAY
FOG LIGHT SWITCH
FUSE 1
HEAD
HI BEAM INDICATOR
HI LO LEFT HEADLAMP
HI LO RIGHT HEADLAMP
HOT AT ALL TIMES
HOT WITH LIGHT SWITCH IN PARK OR HEAD
ILLUMINATION
INSTRUMENT CLUSTER
LEFT FOG LAMP
LT BLU/BLK WIRE
LT BLU/RED WIRE
LT GRN/BLK WIRE
MAIN LIGHT SWITCH
MULTI- FUNCTION SWITCH
NCA WIRE
OFF
OFF PARK
ON INDICATOR
ORG/RED WIRE
PANEL DIMMER SWITCH
PASS PASS HI HI LO LO
POWER DISTRIBUTION BOX
PRIMARY JUNCTION BLOCK
PRIMARY JUNCTION BLOCK PANEL LPS FUSE
RED/BLK WIRE
RED/YEL WIRE
RIGHT FOG LAMP
SECONDARY JUNCTION BLOCK
WHT/PPL WIRE
YEL WIRE
