Electronic power steering circuit, without programmable ride control for Ford Thunderbird X (1988-1997)
Electronic power steering circuit, without programmable ride control
ACTUATOR POWER
ACTUATOR RETURN
BLK WIRE
BRN WIRE
EVO TEST CONNECTOR (RIGHT SIDE OF TRUNK)
FUSE
GROUND
GRY/BLK WIRE
GRY/RED WIRE
HOT IN RUN
IGNITION
LT BLU WIRE
NOT USED
ORG/BLK WIRE
PNK/ORG WIRE
PPL/ORG WIRE
PRIMARY JUNCTION BLOCK
RED WIRE
ROTATION SENSOR
RUN WIRE
SECONDARY JUNCTION BLOCK
STEERING SENSOR
STEERING WHEEL ROTATION SENSOR (BOTTOM OF STEERING COLUMN)
TEST CONN
VEHICLE SPPED SENSOR (VSS) (LEFT REAR OF TRANSMISSION)
VSS
YEL/LT GRN WIRE
