3.8l, a/c circuit, auto a/c for Ford Thunderbird X (1988-1997)

2 STD FUSE 246 57 PPL BLK WIRE BLK/YEL WIRE BLOWER IN-LINE FUSE HOLDER (BEHIND LEFT SIDE OF I/P, TAPED TO HARNESS) BLOWER MOTOR BLOWER MOTOR SPEED CONTROLLER (BEHIND RIGHT SIDE OF I/P) BRN WIRE BRN/ORG WIRE BRN/WHT WIRE BRN/YEL WIRE COLD ENGINE LOCKOUT SWITCH (TOP RIGHT SIDE OF ENGINE) DEF DK BLU/LT GRN WIRE FUSE GRY/YEL WIRE HOT AT ALL TIMES HOT IN RUN HOT IN RUN A/C FUSE IGNITION SWITCH JOINT CONNEC- TOR 1 JOINT CONNECTOR 1 LOCK OFF LOWER RADIATOR SUPPORT) LT GRN WIRE LT GRN/ORG WIRE LT GRN/PPL WIRE MAX NORM NORM MAX PANEL OFF ORG/ WIRE ORG/BLK WIRE ORG/RED WIRE OUTSIDE/ RECIRCULATE SOLENOID (BEHIND RIGHT SIDE OF I/P) PAN/FLR FLR FLR/DEF DEF PANEL OFF PAN/FLR FLR FLR/DEF PNK/BLK WIRE PNK/LT GRN WIRE POWER DISTRIBUTION BOX PPL PPL/ORG WIRE PRIMARY JUNCTION BLOCK RED/ORG WIRE RED/YEL WIRE RUN WIRE SECONDARY JUNCTION BLOCK SEMI-AUTOMATIC TEMPERATURE CONTROL MODULE (CENTER OF I/P) SOLID STATE WHT/LT BLU WIRE WHT/ORG WIRE YEL/WHT WIRE

1995 VFTC 3.8L, 4.6L 4.6L ONLY A/C CLUTCH COIL A/C CLUTCH CONTROL BLEND DOOR ACTUATOR (BEHIND LEFT SIDE OF I/P) BLK WIRE BLK/ORG WIRE BLK/YEL WIRE BRN/ORG WIRE BRN/WHT WIRE DK BLU WIRE DK BLU/LT GRN WIRE EDF RELAY EDF RELAY CONTROL ELECTRIC COOLING FAN ENGINE CONTROLS SYSTEM FL 15 FL 3 FL 5 FUEL PUMP RELAY GRY/WHT WIRE HEDF RELAY HOT AT ALL TIMES HOT IN START OR RUN IN-LINE FUSE LT GRN/ORG WIRE LT GRN/PPL WIRE ORG/ WIRE ORG/BLK WIRE PCM POWER RELAY PNK/LT BLU WIRE PNK/YEL WIRE POWER DISTRIBUTION BOX POWERTRAIN CONTROL MODULE (BEHIND RIGHT COWL PANEL) RED WIRE RED/LT GRN WIRE RED/ORG WIRE RED/YEL WIRE SOLID STATE SUPPORT) TAN/LT GRN WIRE TAN/ORG WIRE YEL WIRE
