Ford Thunderbird X (1988-1997) transmission control indicator Wiring diagrams
This page contains all the electrical diagrams for the component. transmission control indicator, in which he is found in the car Ford Thunderbird X (1988-1997). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram transmission control indicator (1 of 2)
A/T
BLK WIRE
BLK/ORG WIRE
BLU WIRE
CLUSTER FUSE
CLUTCH PEDAL POSITION (CPP) SWITCH (TOP OF CLUTCH PEDAL SUPPORT)
DK GRN/WHT WIRE
ELECTRONIC PRESSURE CONTROL (EPC) SOLENOID
GRN WIRE
GRY/ORG WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT IN RUN
HOT IN RUN OR START
INSTRUMENT CLUSTER
LT BLU/ORG WIRE
LT BLU/YEL WIRE
LT GRN/PPL WIRE
M/T
MANUAL LEVER POSITION (MLP) SENSOR (LEFT REAR OF TRANSMISSION)
ORG/BLK WIRE
ORG/RED WIRE
ORG/WHT WIRE
ORG/YEL WIRE
OUTPUT SHAFT SPEED SENSOR (LEFT SIDE OF TRANSMISSION)
PARK/NEUTRAL POSITION SWITCH (LEFT REAR OF TRANSMISSION)
PNK WIRE
PNK/BLK WIRE
PNK/LT BLU WIRE
PNK/YEL WIRE
PPL
PPL/ORG WIRE
PPL/YEL WIRE
PRIMARY JUNCTION BLOCK
RED WIRE
RED/YEL WIRE
RUN FUSE
SECONDARY JUNCTION BLOCK
SHIFT SOLENOID (SS)
TAN/ORG WIRE
TAN/WHT WIRE
TORQUE CONVERTER CLUTCH (TCC) SOLENOID
TRANSMISSION CONTROL INDICATOR
TRANSMISSION CONTROL SWITCH (TCS) (BELOW FRONT OF CONSOLE)
TRANSMISSION OIL TEMPER- ATURE (TOT) SENSOR
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/LT GRN WIRE
WHT/PNK WIRE
WHT/RED WIRE
WHT/YEL WIRE
Go to component -> Wiring diagram engine performance 3.8ls (3 of 5) -> TRANSMISSION CONTROL INDICATOR
Wiring diagram transmission control indicator (2 of 2)
A/T
BLK WIRE
BLK/ORG WIRE
BLU WIRE
CLUSTER FUSE
CLUTCH PEDAL POSITION (CPP) SWITCH (TOP OF CLUTCH PEDAL SUPPORT)
DK GRN/WHT WIRE
ELECTRONIC PRESSURE CONTROL (EPC) SOLENOID
GRN WIRE
GRY/ORG WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT IN RUN
HOT IN RUN OR START
INSTRUMENT CLUSTER
LT BLU/ORG WIRE
LT BLU/YEL WIRE
LT GRN/PPL WIRE
M/T
MANUAL LEVER POSITION (MLP) SENSOR (LEFT REAR OF TRANSMISSION)
ORG/BLK WIRE
ORG/RED WIRE
ORG/WHT WIRE
ORG/YEL WIRE
OUTPUT SHAFT SPEED SENSOR (LEFT SIDE OF TRANSMISSION)
PARK/NEUTRAL POSITION SWITCH (LEFT REAR OF TRANSMISSION)
PNK WIRE
PNK/BLK WIRE
PNK/LT BLU WIRE
PNK/YEL WIRE
PPL/ORG WIRE
PPL/YEL WIRE
PRIMARY JUNCTION BLOCK
RED WIRE
RED/YEL WIRE
RUN FUSE
SECONDARY JUNCTION BLOCK
SHIFT SOLENOID (SS)
TAN/ORG WIRE
TAN/WHT WIRE
TORQUE CONVERTER CLUTCH (TCC) SOLENOID
TRANSMISSION CONTROL INDICATOR
TRANSMISSION CONTROL SWITCH (TCS) (BELOW FRONT OF CONSOLE)
TRANSMISSION OIL TEMPER- ATURE (TOT) SENSOR
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/LT GRN WIRE
WHT/PNK WIRE
WHT/RED WIRE
WHT/YEL WIRE
Go to component -> Wiring diagram engine performance 3.8l scs (3 of 5) -> TRANSMISSION CONTROL INDICATOR
