Ford Thunderbird X (1988-1997) right instrument panel light wiring diagram
This page shows the only wiring diagram for the component.right instrument panel light, which is found in the car Ford Thunderbird X (1988-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
right instrument panel light wiring diagram (1 of 1)
A/C-HEATER FUNCTION SELECTOR SWITCH
AIR BAG DIAGNOSTIC MONITOR
AIR BAG DIAGNOSTIC MONITOR PHONE SWITCH
ASHTRAY LAMP
BLEND DOOR MOTOR CONTROL
BLK WIRE
BLK/LT GRN WIRE
BLOWER MOTOR SPEED CONTROLLER
BLOWER MOTOR SWITCH
BLOWER RESISTORS
CIGAR LIGHTER
CLOCK SPRING ASSEMBLY
DATA LINK CONNECTOR
ELECTRONIC FLASHER
GRY WIRE
IGNITION SWITCH
INDICATOR LAMP MODULE
INSTRUMENT CLUSTER
INTEGRATED CONTROL MODULE
JOINT CONNECTOR 1
JUNCTION CONNECTOR
LT GRN WIRE
MAIN LIGHT SWITCH LEFT INSTRUMENT PANEL LAMP
MOBILE TELEPHONE TRANSCEIVER PHONE SWITCH
ORG/ WIRE
PANEL DIMMER SWITCH
RADIO
RADIO, AMPLIFIER
REAR WINDOW DEFROST SWITCH
RED WIRE
RIGHT INSTRUMENT PANEL LIGHT
SECONDARY JUNCTION BLOCK
SEMI- AUTOMATIC TEMPERATURE CONTROL MODULE AUTOLAMP DUAL COIL RELAY
SEMI-AUTOMATIC TEMPERATURE CONTROL (SATC) MODULE
SHIFT LOCK ACTUATOR DIGITAL CLOCK
SPEAKER INTERRUPT MODULE
SPEED CONTROL AMPLIFIER POWER ANTENNA MODULE
SPEED CONTROL SWITCH ASSEMBLY
TRANSMISSION RANGE (TR) INDICATOR
W/O SATC
W/SATC
Go to component -> Ground distribution circuit (2 of 4) -> RIGHT INSTRUMENT PANEL LIGHT
