Ford Thunderbird X (1988-1997) main light sw Wiring diagram
This page shows the only wiring diagram for the component.main light sw, which is found in the car Ford Thunderbird X (1988-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram main light sw (1 of 1)
158 BLK/PNK WIRE
159 RED/PNK WIRE
257 WHT/RED WIRE
3.8L (W/MT)
4.6L
450 DK GRN/LT GRN WIRE
462 PPL
465 WHT/LT BLU WIRE
57 BLK WIRE
85 BRN/LT BLU WIRE
BATTERY
BLK WIRE
BLK/PNK WIRE
BRN/LT BLU WIRE
BRN/ORG 924 WIRE
CLUSTER
DK GRN/LT GRN WIRE
DOOR COURTESY LAMP SW IN
DOOR INPUT
FASTEN BELT IND
GROUND
HEAD
HOT AT ALL TIMES
HOT IN ACC OR RUN
HOT IN START OR RUN
IGNITION
INT LPS
INTEGRATED CONTROL MODULE (BEHIND LEFT SIDE OF INST PANEL)
JUNCTION CONNECTOR (BEHIND LEFT SIDE OF INST PANEL, ABOVE STEERING COLUMN)
KEY WARNING SW (INSIDE IGNITION SW)
KEY-IN-IGN IN
LAMPS IN
LEFT DOOR COURTESY LAMP SW (IN LEFT DOOR JAMB)
LT GRN/YEL WIRE
MAIN LIGHT SW
NCA WIRE
OFF
PARK
POWERTRAIN CONTROL MODULE (PCM) (BEHIND RIGHT COWL PANEL)
PPL
PPL 462
PRIMARY JUNCTION BLOCK (BEHIND INST PANEL, LEFT OF STEERING COLUMN)
RED/PNK WIRE
SEATBELT BUCKLE IN
SEATBELT SW (IN LEFT SEATBELT BUCKLE ASSEMBLY)
SUPERCOUPE ONLY
WARNING CHIME MODULE
WHT/LT BLU WIRE
Go to component -> Instrument cluster circuit (3 of 4) -> MAIN LIGHT SW
