Ford Thunderbird X (1988-1997) hard ride relay Wiring diagram
This page shows the only wiring diagram for the component.hard ride relay, which is found in the car Ford Thunderbird X (1988-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hard ride relay (1 of 1)
25 20 (4.6L) (3.8L)
4.6L ONLY
BLK WIRE
BLK/YEL WIRE
CKP SENSOR SHIELD
CMP SENSOR SHIELD
ELECTRONIC VARIABLE ORIFICE (EVO) MODULE AUTOMATIC SHOCK CONTROL MODULE
FOG LAMP SWITCH
FROM GROUND
FUEL PUMP/ FUEL GAUGE SENDER
HARD RIDE RELAY
ICM SHIELD
LEFT BACKUP LAMP
LEFT LED BAR
LEFT LICENSE LAMP
LUGGAGE COMPARTMENT LAMP
PASSENGER'S POWER LUMBAR/ BOLSTER COMPRESSOR MOTOR
PASSENGER'S SEAT CONTROL SWITCH
POWERTRAIN CONTROL MODULE
REAR WINDOW DEFROST GRID
RIGHT BACKUP LAMP
RIGHT DOOR COURTESY LAMP
RIGHT DOOR LOCK SWITCH
RIGHT LED BAR
RIGHT LICENSE LAMP
RIGHT LOCK CYLINDER ILLUMINATION LAMP
RIGHT POWER WINDOW SWITCH
RIGHT REAR COURTESY LAMP
SOFT RIDE RELAY
TRUNK LID RELEASE SOLENOID
W/O REMOTE KEYLESS ENTRY
W/REMOTE KEYLESS ENTRY
Go to component -> Ground distribution circuit (4 of 4) -> HARD RIDE RELAY
