Ford Thunderbird X (1988-1997) engine coolant level sensor left front park lamp Wiring diagram
This page shows the only wiring diagram for the component.engine coolant level sensor left front park lamp, which is found in the car Ford Thunderbird X (1988-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine coolant level sensor left front park lamp (1 of 1)
3.8L SC ENGINE COOLING FAN MOTOR
3.8L SC INTEGRATED RELAY CONTROL MODULE IGNITION CONTROL MODULE
3.8L SC ONLY
3.8L/3.8L SC
4.6L
A/C HIGH PRESSURE CUTOUT/FAN SWITCH
ABS TEST CONNECTOR
ANTI- LOCK POWER RELAY
ANTI- LOCK PUMP MOTOR RELAY
ANTI-LOCK BRAKE CONTROL MODULE
ANTI-LOCK BRAKE MOTOR SENSOR SHIELD
BATTERY
BLK WIRE
BLK/YEL WIRE
BRAKE FLUID LEVEL SWITCH
BRAKE SENSOR SHIELDS
CAMSHAFT POSITION SENSOR
DATA LINK CONNECTOR
DATA LINK CONNECTOR W/ABS
EI ONLY
ENGINE COMPARTMENT LAMP
ENGINE COOLANT LEVEL SENSOR LEFT FRONT PARK LAMP
ENGINE COOLING PUSHER FAN
FOG LAMP RELAY
HEATED OXYGEN SENSOR 1
HEATED OXYGEN SENSOR 2
IGNITION CONTROL MODULE
LEFT FOG LAMP
LEFT FRONT
LEFT FRONT PARK/ TURN LAMP
LEFT HEADLAMP
LEFT REAR RIGHT FRONT
LT GRN WIRE
MASS AIR FLOW (MAF SENSOR)
NCA WIRE
POWER- TRAIN CONTROL MODULE
POWERTRAIN CONTROL MODULE (PCM)
RIGHT FOG LAMP
RIGHT FRONT PARK LAMP
RIGHT FRONT PARK/ TURN LAMP
RIGHT HEADLAMP
RIGHT REAR
SOLENOID CONTROL VALVE BODY
W/ABS
W/O ABS
WASHER MOTOR
WHT WIRE
WINDSHIELD WIPER MOTOR
YEL WIRE
Go to component -> Ground distribution circuit (1 of 4) -> ENGINE COOLANT LEVEL SENSOR LEFT FRONT PARK LAMP
