Trunk release circuit, with intelligent access for Ford Taurus VI (2009-2012)
Trunk release circuit, with intelligent access
1 2 PWR LOGIC
15 22 TRUNK RELEASE TRUNK AJAR
5 15 TRUNK RELEASE EXT TRUNK
BATTERY SAVER RELAY
BLK/GRY WIRE
BLK/VIO WIRE
BLU WIRE
BLU/RED WIRE
BRN/BLU WIRE
BRN/YEL WIRE
FUSE
GRN WIRE
GRN/RED WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
LUGGAGE COMPARTENT LAMP
LUGGAGE COMPARTMENT LID RELEASE SWITCH
MICRO -
RED WIRE
REMOTE FUNCTION ACTUATOR (RFA) MODULE (RIGHT SIDE OF DASH)
SMART JUNCTION BOX (SJB) (LEFT KICK PANEL)
VIO/GRY WIRE
WHT/BLU WIRE
YEL WIRE
YEL/GRN WIRE
YEL/ORG WIRE
