Ford Taurus VI (2009-2012) Base radio circuit

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 VBATT AM/FM ANT AM/FM ANTENNA ANT PWR ANTENNA MODULE (RIGHT "C" PILLAR) AUDIO CONTROL MODULE (ACM) (CENTER OF DASH) AUDIO INPUT JACK AUDIO MUTE BLK WIRE BLK/BLU WIRE BLU WIRE BLU/GRN WIRE BRN/BLU WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM FUSE 28 FUSE 39 GRY/ORG WIRE GRY/VIO WIRE HOT AT ALL TIMES HOT IN START LEFT FRONT SPEAKER LEFT REAR SPEAKER LF SPKR+ LR SPKR+ RR SPKR+ RF SPKR+ RF SPKR- GND LF SPKR- LR SPKR- RR SPKR- MS CAN - MS CAN + NCA WIRE ORG/ WIRE RED WIRE REMOTE FUNCTION ACTUATOR (RFA) MODULE (RIGHT SIDE OF DASH) RIGHT FRONT SPEAKER RIGHT REAR SPEAKER SHIELD SMART JUNCTION BOX (SJB) (LEFT KICK PANEL) VIO/ORG WIRE W/ IA W/0 IA WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/ORG WIRE WHT/RED WIRE WHT/VIO WIRE YEL/GRN WIRE
