Power seats circuit, 10-way passenger seat for Ford Taurus VI (2009-2012)
Power seats circuit, 10-way passenger seat
BLK/WHT WIRE
BRN/GRN WIRE
FRONT HEIGHT
FWD AFT
GRN/BLU WIRE
GRN/ORG WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/RED WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HORIZONTAL
HOT AT ALL TIMES BATTERY JUNCTION FUSE 5 BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
INCLINE RECLINE
INFLATE DEFLATE
LUMBAR
PASSENGER LUMBAR MOTOR (IN FRONT PASSENGER'S SEAT BACK)
PASSENGER SEAT FRONT HEIGHT MOTOR (UNDER FRONT PASSENGER'S SEAT)
PASSENGER SEAT HORIZONTAL MOTOR (UNDER FRONT PASSENGER'S SEAT)
PASSENGER SEAT REAR HEIGHT MOTOR (UNDER FRONT PASSENGER'S SEAT)
PASSENGER SEAT RECLINER MOTOR (UNDER FRONT PASSENGER'S SEAT)
PASSENGER SIDE FRONT SEAT CONTROL SWITCH
REAR HEIGHT
RECLINE
UP DOWN
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/RED WIRE
WHT WIRE
WHT/BLU WIRE
WHT/ORG WIRE
YEL/GRY WIRE
