Car Wiring Diagrams for Blind spot information system circuit for Ford Taurus VI (2009-2012)

1 2 3 4 5 6 ALERT RUN/START MS CAN+ MS CAN- GND 1 2 3 4 5 6 ALERT RUN/START MS CAN+ MS CAN- GND GND BLK WIRE BLK/BLU WIRE BLK/GRY WIRE BLK/YEL WIRE BLU/BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER SIDE EXTERIOR REAR VIEW MIRROR (DRIVER'S DOOR) FUSE 35 GRY/ORG WIRE HOT IN RUN OR START LEFT EXTERIOR MIRROR BLIND SPOT (BLIS)/ CROSS TRAFFIC ALERT (CTA) LED LEFT SIDE OBSTACLE DETECTION CONTROL MODULE (SOD-L) (LEFT END OF REAR BUMPER) NCA WIRE RIGHT EXTERIOR MIRROR BLIND SPOT (BLIS)/ CROSS TRAFFIC ALERT (CTA) LED RIGHT SIDE OBSTACLE DETECTION CONTROL MODULE (SOD-R) (RIGHT END OF REAR BUMPER) SMART JUNCTION BOX (SJB) (LEFT KICK PANEL) VIO/ORG WIRE YEL/GRN WIRE YEL/GRY WIRE
