Ford Taurus VI (2009-2012) w/ halogen headlamps Wiring diagrams
This page contains all the electrical diagrams for the component. w/ halogen headlamps, in which he is found in the car Ford Taurus VI (2009-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
w/ halogen headlamps wiring diagram (1 of 2)
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPARTMENT)
BLOWER MOTOR RELAY
BLU WIRE
BRN WIRE
CRUISE CONTROL MODULE (CCM)
DAYTIME RIGHT RUNNING HEADLAMP LAMPS (W/ HID RELAY 2 HEADLAMPS)
DIODE
FLOOR SHIFTER
FROM FUSE 28 (DIAGRAM 1 OF 5)
FUSE
FUSE 13
FUSE 20 FUSE 10
FUSE 24
FUSE 25
FUSE 26
FUSE 33
FUSE 35
FUSE 4 FUSE 27
GRN WIRE
GRY WIRE
IGNITION LOCK SOLENOID
IGNITION SWITCH
KEY-IN IGNITION SWITCH
MICRO -
MICRO TURBO EXCEPT TURBO
OFF
ORG/ WIRE
POWERTRAIN CONTROL MODULE (PCM)
REAR WINDOW DEFROST HIGH BEAM RAIN RELAY CONTROL SENSOR MODULE MODULE (HCM-2)
RED WIRE
REVERSING LAMPS RELAY
RIGHT HEADLAMP RELAY
RUN WIRE
SMART JUNCTION BOX (SJB) (LEFT KICK PANEL) FUSE
SMRC
STARTER A/C REAR RELAY CLUTCH WINDOW RELAY DEFROST RELAY
STOP LAMP RELAY
TO FUSE 16 (DIAGRAM 5 OF 5)
TO FUSE 27 (DIAGRAM 4 OF 5)
TO REMOTE FUNCTION ACTUATOR (RFA) (DIAGRAM 5 OF 5)
TO RUN/START RELAY (DIAGRAM 4 OF 5)
VIO WIRE
W/ DRL
W/ HALOGEN HEADLAMPS
W/ IA
W/O IA
W/O IA W/ IA
WHT WIRE
WIPER FUEL RUN/PARK PUMP (FP) RELAY RELAY
YEL WIRE
Go to component -> Power distribution circuit (2 of 5) -> W/ HALOGEN HEADLAMPS
w/ halogen headlamps wiring diagram (2 of 2)
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPARTMENT)
BLU WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BRN WIRE
BRN/VIO WIRE
DAYTIME RUNNING LAMPS RELAY 1
EVAP CANISTER VENT CONTROL SOLENOID
FROM FUSE 33 (DIAGRAM 2 OF 5)
FROM FUSE 35 (DIAGRAM 4 OF 5)
FROM FUSE 41 (DIAGRAM 3 OF 5)
FROM FUSE 43 (DIAGRAM 2 OF 5)
FROM IGNITION SWITCH (DIAGRAM 2 OF 5)
FROM SMART JUNCTION BOX (SJB) (DIAGRAM 2 OF 5)
FROM START DIODE (DIAGRAM 2 OF 5)
FUSE
FUSE 11
FUSE 16
FUSE 23
FUSE 29 FUSE 36
FUSE 32
FUSE 38
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
GRY/YEL WIRE
HEADS UP DISPLAY (HUD) MODULE (W/ ADAPTIVE CRUISE)
INSTRUMENT CLUSTER (IC) PASSIVE ANTI-THEFT TRANSCEIVER (W/O IA)
LEFT FRONT POWER WINDOW MOTOR
LEFT HEADLAMP (W/ HID HEADLAMPS)
LEFT HEADLAMP RELAY
LEFT SIDE DOOR LOCK SWITCH
MASTER WINDOW ADJUST MOTOR
ORG/ WIRE
PCM POWER RELAY
POWERTRAIN CONTROL MODULE (PCM)
RED WIRE
REMOTE FUNCTION ACTUATOR (RFA) (W/ IA)
RESTRAINTS CONTROL MODULE (RCM)
RIGHT FRONT POWER WINDOW MOTOR (W/ ONE-TOUCH UP/DOWN PASSENGER WINDOW)
RIGHT SIDE DOOR LOCK SWITCH
RUN LED
SMART JUNCTION BOX (SJB) (LEFT KICK PANEL)
SS 1
SS 2
START RLY
START/STOP SWITCH (W/ IA)
TURBO EXCEPT TURBO
VIO WIRE
VIO/BRN WIRE
VIO/GRN WIRE
W/ DRL
W/ HALOGEN HEADLAMPS
WHT WIRE
WHT/BRN WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Power distribution circuit (5 of 5) -> W/ HALOGEN HEADLAMPS
