Ford Taurus VI (2009-2012) left front auxiliary park lamp Wiring diagram
This page shows the only wiring diagram for the component.left front auxiliary park lamp, which is found in the car Ford Taurus VI (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front auxiliary park lamp (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLU/GRN WIRE
BRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
FUSE 22
FUSE 6
GRN/ORG WIRE
GRY WIRE
GRY/ORG WIRE
GRY/YEL WIRE
HAZARD BPP GND
HEADLAMP SWITCH PARK LOW AUTO OFF
HOT AT ALL TIMES
INSTRUMENT CLUSTER (IC)
LEFT FRONT AUXILIARY PARK LAMP
LEFT FRONT PARK/ TURN LAMP TURN
LEFT FRONT TURN LAMP (FET)
LEFT OFF TURN TURN
LEFT REAR TURN LAMP (FET)
LEFT RIGHT FRONT FRONT SIDE SIDE MARKER MARKER LAMP LAMP
LOW AUTO BEAM
MICRO -
MS MS CAN CAN
MULTI- FUNCTION SWITCH
OFF PARK
PARK
PARK LAMP RELAY
RIGHT
RIGHT FRONT AUXILIARY PARK LAMP
RIGHT FRONT PARK/ TURN LAMP TURN
RIGHT FRONT TURN LAMP (FET)
RIGHT LEFT TURN TURN
RIGHT REAR TURN LAMP (FET)
SMART JUNCTION BOX (SJB) (LEFT KICK PANEL)
TRACTION CTL ON/OFF
VIO/GRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
W/ AUXILIARY PARK LAMPS
WHT/VIO WIRE
YEL/GRY WIRE
YEL/VIO WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> LEFT FRONT AUXILIARY PARK LAMP
