Ford Taurus VI (2009-2012) exterior door handle Wiring diagrams
This page contains all the electrical diagrams for the component. exterior door handle, in which he is found in the car Ford Taurus VI (2009-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram exterior door handle (1 of 2)
19 7 1 MS CAN + MS CAN - DOOR LOCK
6 5 4 12 DOOR UNLOCK DOOR LOCK ALARM SET ALARM RESET
AJAR
AJAR SWITCH
BACKUP TRANSCEIVER (UNDER CENTER CONSOLE)
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLK/GRY WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BPP
BRN/GRN WIRE
BRN/VIO WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
CONSOLE FRONT ANTENNA (UNDER CENTER CONSOLE)
CONSOLE REAR ANTENNA (UNDER CENTER CONSOLE)
DATA CLK PATS VCC
DRIVER DOOR MODULE (DDM) (DRIVER'S DOOR)
EXTERIOR DOOR HANDLE
FLA FLA RTN
FUSE
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRY/BLU WIRE
GRY/ORG WIRE
GRY/RED WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOOD SWITCH (LEFT FRONT OF ENGINE COMPT)
LEFT FRONT
LEFT FRONT DOOR LATCH (DRIVER'S DOOR)
LEFT LUGGAGE COMPARTMENT LAMP
LEFT SIDE DOOR LOCK SWITCH
LOCK
LUGGAGE COMPARTMENT LID RELEASE SOLENOID
PATS GND
POWER WINDOWS SYSTEM
RELAY
REMOTE FUNCTION ACTUATOR (RFA) (RIGHT SIDE OF DASH)
RIA R/S RELAY COIL
RUN/
SEAT ANTENNA (BEHIND RIGHT SIDE OF REAR SEAT)
SET/ RESET
SOLID STATE
START RLY COIL
STARTING/CHARGING SYSTEM
STARTING/CHARGING SYSTEM EXTERIOR LIGHTS SYSTEM
TRUNK TRUNK RTN
TRUNK, TAILGATE, FUEL DOORS SYSTEM
UNLOCK
VIO WIRE
VIO/GRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
W/ PERIMETER ALARM
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/ORG WIRE
YEL WIRE
YEL/GRY WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Forced entry circuit, with intelligent access (2 of 2) -> EXTERIOR DOOR HANDLE
Wiring diagram exterior door handle (2 of 2)
19 7 1 MS CAN + MS CAN - DOOR LOCK
6 5 4 12 DOOR UNLOCK DOOR LOCK ALARM SET ALARM RESET
AJAR
AJAR SWITCH
BACKUP TRANSCEIVER (UNDER CENTER CONSOLE)
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLK/GRY WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BPP
BRN/GRN WIRE
BRN/VIO WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
CONSOLE FRONT ANTENNA (UNDER CENTER CONSOLE)
CONSOLE REAR ANTENNA (UNDER CENTER CONSOLE)
DATA CLK PATS VCC
DRIVER DOOR MODULE (DDM) (DRIVER'S DOOR)
EXTERIOR DOOR HANDLE
FLA FLA RTN
FUSE
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRY/BLU WIRE
GRY/ORG WIRE
GRY/RED WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOOD SWITCH (LEFT FRONT OF ENGINE COMPT)
LEFT FRONT
LEFT FRONT DOOR LATCH (DRIVER'S DOOR)
LEFT LUGGAGE COMPARTMENT LAMP
LEFT SIDE DOOR LOCK SWITCH
LOCK
LUGGAGE COMPARTMENT LID RELEASE SOLENOID
PATS GND
POWER WINDOWS SYSTEM
RELAY
REMOTE FUNCTION ACTUATOR (RFA) (RIGHT SIDE OF DASH)
RIA R/S RELAY COIL
RUN/
SEAT ANTENNA (BEHIND RIGHT SIDE OF REAR SEAT)
SET/ RESET
SOLID STATE
START RLY COIL
STARTING/CHARGING SYSTEM
STARTING/CHARGING SYSTEM EXTERIOR LIGHTS SYSTEM
TRUNK TRUNK RTN
TRUNK, TAILGATE, FUEL DOORS SYSTEM
UNLOCK
VIO WIRE
VIO/GRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
W/ PERIMETER ALARM
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/ORG WIRE
YEL WIRE
YEL/GRY WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Power door locks circuit, with intelligent access (2 of 2) -> EXTERIOR DOOR HANDLE
