Ford Taurus VI (2009-2012) dim up Wiring diagrams
This page contains all the electrical diagrams for the component. dim up, in which he is found in the car Ford Taurus VI (2009-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram dim up (1 of 3)
2 4 DOME GND
AJAR FL
AJAR FR
AJAR LEFT FRONT DOOR LATCH
AJAR LEFT REAR DOOR LATCH
AJAR LR
AJAR RIGHT FRONT DOOR LATCH
AJAR RIGHT REAR DOOR LATCH
AJAR RR
BATTERY SAVER RELAY
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
DIM DOWN
DIM SW GND
DIM UP
DOME LP
DRV DOOR AJAR
EARLY PRODUCTION LATE PRODUCTION
FRONT INTERIOR/MAP LAMPS ASSEMBLY
FUSE
FUSE FUSE FUSE
GRN WIRE
GRN/BLU WIRE
GRN/VIO WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HOMELINK MODULE
HOT AT ALL TIMES
HS CAN+
INSTRUMENT ILLUMINATION CIRCUIT
INSTRUMENT PANEL DIMMER SWITCH
INTERIOR LIGHTING (FET)
LEFT VANITY MIRROR LAMP
LR DOOR AJAR
LUGGAGE COMPARTMENT LAMP
MICRO -
OFF
OFF FUSE
PASS DOOR AJAR
PASSENGER SIDE EXTERIOR REAR VIEW MIRROR (PASSENGER'S DOOR)
POWERTRAIN CONTROL MODULE (PCM) (TURBO) (REAR OF ENGINE COMPT)
PUDDLE LED (FET)
PWM INPUT
REAR INTERIOR/MAP LAMPS ASSEMBLY
RED WIRE
REMOTE FUNCTION ACTUATOR (RFA) MODULE (RIGHT SIDE OF DASH)
RIGHT VANITY MIRROR LAMP
RR DOOR AJAR
SMART JUNCTION BOX (SJB)
TRUNK, TAILGATE, FUEL DOORS SYSTEM
VIO WIRE
VIO/GRY WIRE
VIO/RED WIRE
W/ IA
W/O IA
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/ORG WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Courtesy lamps circuit (1 of 2) -> DIM UP
Wiring diagram dim up (2 of 3)
1 2 3 4 LED-GREEN LED-BLUE LED-RETURN
AMBIENT LIGHTING SWITCH
BLK/BLU WIRE
BLK/VIO WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DIM UP
DOOR RELEASE HANDLE
GRN WIRE
GRY/ORG WIRE
INSTRUMENT ILLUMINATION CIRCUIT
INTERIOR LIGHTING CONTROL MODULE (ILCM)
LED RED WIRE
LED RETURN
LED-RETURN LED-BLUE LED-GREEN 4 3 2 1
LEFT FRONT DOOR LED
LEFT FRONT FOOTWELL LAMP
LEFT REAR FOOTWELL LAMP
MAP POCKET
MS CAN - MS CAN +
NCA WIRE
ORG/ WIRE
PIGTAIL HARNESS
PULL HANDLE
RIGHT FRONT DOOR LED
RIGHT FRONT FOOTWELL LAMP
RIGHT REAR FOOTWELL LAMP
STORAGE BIN LAMP
TOGGLE 2 7 4
TOP FINISH PANEL LAMP
VBATT SW PUSHBUTTON SW UP GND
VIO/GRY WIRE
VIO/ORG WIRE
VIO/RED WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> DIM UP
Wiring diagram dim up (3 of 3)
