Ford Taurus VI (2009-2012) accessory protocol interface module (aipm) (under center console) wiring diagram
This page shows the only wiring diagram for the component.accessory protocol interface module (aipm) (under center console), which is found in the car Ford Taurus VI (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
accessory protocol interface module (aipm) (under center console) wiring diagram (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 VPWR REVERSE GND
24 23 COMPASS + COMPASS -
5 6 MIC+ MIC-
ACCESSORY DELAY RELAY
ACCESSORY PROTOCOL INTERFACE MODULE (AIPM) (UNDER CENTER CONSOLE)
AUTO DIMMING INTERIOR MIRROR
BLK WIRE
BLK/GRY WIRE
BLU WIRE
BLU/GRY WIRE
BRN WIRE
BRN/VIO WIRE
CHOKE
DECKLID
DRIVER SIDE EXTERIOR REAR VIEW MIRROR (DRIVER'S DOOR)
ELECTRONICS
FUSE 35
FUSE 41
GRN/BRN WIRE
GRY WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
INSTRUMENT PANEL CLUSTER (IPC)
MIC + SHIELD RR CAM VIDEO+ COMPASS + COMPASS - MIRROR +
MIC - MIRROR - RR CAM VIDEO-
MICRO -
NCA WIRE
RED WIRE
SMART JUNCTION BOX (SJB) (LEFT KICK PANEL)
SPOILER
VIDEO CAMERA (CENTER REAR OF LUGGAGE COMPT LID)
WHT WIRE
WHT/GRN WIRE
YEL WIRE
YEL/GRN WIRE
YEL/GRY WIRE
Go to component -> Electrochromic mirror circuit, with rear view camera -> ACCESSORY PROTOCOL INTERFACE MODULE (AIPM) (UNDER CENTER CONSOLE)
