Cooling fan circuit for Ford Taurus V (2007-2009)

Cooling fan circuit

Taurus Ford V (2007-2009): Cooling fan circuit

Get access

1 4 2 PWR FAN CTRL VARIABLE GND 2 3 HS CAN + HS CAN - BATTERY JUNCTION BLK/GRY WIRE BLU WIRE BLU/GRY WIRE CHT COMPUTER DATA LINES SYSTEM CYLINDER HEAD TEMPERATURE SENSOR (TOP FRONT OF RIGHT CYLINDER HEAD) E-SIGRTN ELECTRONICS ENGINE CONTROLS SYSTEM ENGINE COOLING FAN MOTOR (FRONT OF ENGINE COMPARTMENT, BEHIND RADIATOR) FAN CTRL VARIABLE FUSE 7 BOX (BJB) (LEFT SIDE OF OF ENGINE COMPT) GRN WIRE GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES NCA WIRE POWERTRAIN CONTROL MODULE (REAR OF ENGINE COMPT) WHT WIRE WHT/BLU WIRE WHT/RED WIRE
