Ford Taurus V (2007-2009) decklid sw Wiring diagram

This page shows the only wiring diagram for the component.decklid sw, which is found in the car Ford Taurus V (2007-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram decklid sw (1 of 1)

Wiring diagram decklid sw for Ford Taurus V (2007-2009)

Get access

BATTERY SAVER RELAY BLK WIRE BLU WIRE BRN WIRE DECKLID AJAR SW DECKLID LATCH ASSEMBLY (CENTER REAR OF DECKLID) DECKLID RELEASE RELAY DECKLID RELEASE SWITCH DECKLID SW FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES ILLUMINATION LUGGAGE COMPARTMENT (UNDER CENTER LAMP CONSOLE) MICRO - ORG/ WIRE SMART JUNCTION BOX (SJB) (UNDER LEFT SIDE OF DASH) VIO WIRE WHT WIRE YEL WIRE

Go to component: -> Trunk release circuit -> DECKLID SW
