Ford Taurus IV facelift (2004-2006) window switch down in wiring diagram
This page shows the only wiring diagram for the component.window switch down in, which is found in the car Ford Taurus IV facelift (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
window switch down in wiring diagram (1 of 1)
ACCES- SORY RELAY CTRL
ACCESSORY RELAY
BATTERY SAVER RELAY
BATTERY SAVER RELAY CTRL
BLK WIRE
CIRCUIT BREAKER 10
DN UP
DN UP DN
DN UP DN UP
DN UP UP DN
DN UP UP DN ONE- TOUCH DOWN SWITCH
DOOR LOCKS SYSTEM
DRIVER SIDE FRONT POWER WINDOW MOTOR (LEFT FRONT DOOR)
DRIVER WINDOW SWITCH
FUSE 30
GRY/LT BLU WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
LEFT REAR POWER WINDOW MOTOR (LEFT REAR DOOR)
LEFT REAR WINDOW ADJUST SWITCH
LEFT REAR WINDOW SWITCH
LOW CURRENT BOARD
LT BLU WIRE
LT BLU/BLK WIRE
MASTER WINDOW ADJUST SWITCH
ONE TOUCH HIGH SENSE
ONE TOUCH LOW SENSE
ONE TOUCH WINDOW RELAY CTRL
ONE-TOUCH WINDOW RELAY
ORG/WHT WIRE
PASSENGER SIDE FRONT POWER WINDOW MOTOR (RIGHT FRONT DOOR)
PASSENGER SIDE WINDOW ADJUST SWITCH
PASSENGER WINDOW SWITCH
POWER TOPS SYSTEM
RED/BLK WIRE
RED/LT BLU WIRE
RED/YEL WIRE
RESISTOR
RIGHT REAR POWER WINDOW MOTOR (RIGHT REAR DOOR)
RIGHT REAR WINDOW ADJUST SWITCH
RIGHT REAR WINDOW SWITCH
SMART JUNCTION BOX (UNDER LEFT SIDE OF DASH)
TAN/LT BLU WIRE
UP DN
UP DN UP DN
WHT/BLK WIRE
WHT/LT BLU WIRE
WHT/YEL WIRE
WINDOW LOCKOUT SWITCH
WINDOW SWITCH DOWN IN
WINDOW SWITCH UP IN
YEL/BLK WIRE
YEL/LT BLU WIRE
YEL/RED WIRE
Go to component -> Power windows circuit -> WINDOW SWITCH DOWN IN
