Ford Taurus IV facelift (2004-2006) rear window wiper/ washer switch Wiring diagrams

This page contains all the electrical diagrams for the component. rear window wiper/ washer switch, in which he is found in the car Ford Taurus IV facelift (2004-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram rear window wiper/ washer switch (1 of 2)

Wiring diagram rear window wiper/ washer switch for Ford Taurus IV facelift (2004-2006)

Get access

AIR BAG SLIDING CONTACT AUTOMATIC A/C AUTOMATIC A/C MANUAL A/C BLK WIRE BRAKE SHIFT INTERLOCK DATA LINK CONNECTOR (DLC) ELECTRO- CHROMATIC INSIDE MIRROR UNIT RIGHT VANITY MIRROR LAMP ELECTRONIC COMPASS FLEXIBLE FUEL SENSOR MODULE FLOOR SHIFT FRONT BLOWER MOTOR SPEED CONTROLLER FRONT BLOWER MOTOR RESISTOR ASSEMBLY FRONT CIGAR LIGHTER FUNCTION SELECTOR SWITCH ASSEMBLY INSTRUMENT CLUSTER INTEGRATED CONTROL PANEL LEFT VANITY MIRROR LAMP MAIN LIGHT SWITCH MAP READING LAMPS MESSAGE CENTER SWITCH MULTI- FUNCTION SWITCH NCA WIRE PASSENGER SIDE DOOR LOCK SWITCH PASSENGER SIDE EXTERIOR REAR VIEW MIRROR PASSIVE ANTI-THEFT TRANSCEIVER MODULE POWER POINT PRNDL ILLUMINATION LAMP REAR WINDOW WIPER/ WASHER SWITCH REMOTE CLIMATE CONTROL (RCC) MODULE RIGHT FRONT DOOR AJAR SWITCH ROOF OPENING PANEL MODULE FRONT INTERIOR LAMPS FRONT INTERIOR LAMPS SUNLOAD/ AUTOLAMP SENSOR TEMPERATURE BLEND DOOR ACTUATOR TRACTION CONTROL SWITCH W/ FLEX FUEL W/ MANUAL A/C W/ POWER LOCKS W/ ROOF OPENING PANEL W/O ROOF OPENING PANEL WAGON YEL WIRE

Go to component: -> Ground distribution circuit (2 of 3) -> REAR WINDOW WIPER/ WASHER SWITCH

Wiring diagram rear window wiper/ washer switch (2 of 2)

Wiring diagram rear window wiper/ washer switch for Ford Taurus IV facelift (2004-2006)

Get access

BLK WIRE BLK/PNK WIRE DK BLU WIRE FUSE 22 HOT IN RUN OR ACC LT GRN WIRE ORG/ WIRE PARK PNK 2 WIRE REAR WINDOW WIPER/ WASHER SWITCH REAR WIPER MOTOR ASSEMBLY (IN LIFTGATE) RUN WIRE SMART JUNCTION BOX (UNDER LEFT SIDE OF DASH) SOLID STATE SWITCH ILLUM. WASHER SWITCH WHT WIRE

Go to component: -> Rear wiper/washer circuit -> REAR WINDOW WIPER/ WASHER SWITCH
