Ford Taurus IV facelift (2004-2006) passenger side front seat adjust switch Wiring diagrams

ACCES- SORY RELAY ADJUSTABLE PEDAL SWITCH (EARLY PRODUCTION) BATTERY JUNCTION BOX BLK WIRE DEACTIVATOR SWITCH BRAKE PEDAL POSITION SWITCH DRIVER SIDE FRONT SEAT ADJUST SWITCH EARLY PRODUCTION FLEXIBLE FUEL SENSOR MODULE PASSIVE ANTI-THEFT TRANSCEIVER MODULE FOG LAMP RELAY FROM FROM FUSE 3 (DIAGRAM 1 OF 3) FRONT CIGAR LIGHTER FUSE FUSE 10 FUSE 16 FUSE 20 FUSE 32 FUSE 36 FUSE 7 FUSE FUSE GRN WIRE GRY WIRE IGNITION SWITCH INSTRUMENT CLUSTER INTEGRATED CONTROL PANEL INTEGRATED CONTROL PANEL ELECTRONIC COMPASS LATE PRODUCTION LOCK OFF LOW CURRENT BOARD LT BLU WIRE LT GRN WIRE LT GRN/VIO WIRE LT LT LT LT (LEFT SIDE OF DASH, BEHIND INSTRUMENT CLUSTER) LT LT LT MULTI- FUNCTION SWITCH NCA WIRE PASSENGER SIDE FRONT SEAT ADJUST SWITCH PCM POWER RELAY POWER POINT REAR WINDOW DEFROST RELAY 1 RED WIRE RELAY CENTER BOX 1 (LEFT FRONT OF ENGINE COMPARTMENT) REMOTE CLIMATE CONTROL (RCC) MODULE RESTRAINTS CONTROL MODULE SEAT WEIGHT SENSOR MODULE RUN WIRE SMART JUNCTION BOX (UNDER LEFT SIDE OF DASH) TO FUSE 21 (SMART JUNCTION BOX) (DIAGRAM 3 OF 3) TO FUSE 22 (SMART JUNCTION BOX) (DIAGRAM 3 OF 3) TO FUSE 27 (SMART JUNCTION BOX) (DIAGRAM 3 OF 3) VIO WIRE VPWR WHT WIRE YEL WIRE

BLK WIRE CIRCUIT BREAKER 10 DRIVER SIDE FRONT SEAT ADJUST SWITCH ENTIRE SEAT FORWARD/ REARWARD MOTOR FRONT OF SEAT FRONT UP/DOWN MOTOR HOT AT ALL TIMES LEFT POWER SEAT MOTOR ASSEMBLY (UNDER DRIVER SEAT) LT BLU WIRE LT GRN WIRE NCA WIRE PASSENGER SIDE FRONT SEAT ADJUST SWITCH REAR OF SEAT REAR UP/DOWN MOTOR RED WIRE RIGHT POWER SEAT MOTOR ASSEMBLY SMART JUNCTION BOX (UNDER LEFT SIDE OF DASH) WHT WIRE YEL WIRE
