Ford Taurus IV facelift (2004-2006) left license plate lamp high mounted stoplamp Wiring diagram
This page shows the only wiring diagram for the component.left license plate lamp high mounted stoplamp, which is found in the car Ford Taurus IV facelift (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left license plate lamp high mounted stoplamp (1 of 1)
ABS CONTROL MODULE
BLK WIRE
BLK/WHT WIRE
CARGO SPACE LAMP
FUEL PUMP DRIVER MODULE
LEFT LICENSE PLATE LAMP HIGH MOUNTED STOPLAMP
LEFT REAR SIDE LAMP LUGGAGE COMPARTMENT LID RELEASE SOLENOID
LEFT REAR TURN LAMP
LEFT REAR TURN LAMP LEFT REAR SIDE LAMP LEFT TAIL LAMP
LEFT RIGHT REAR REAR PARK/ PARK/ RIGHT TAIL LAMP TURN TURN LAMP LAMP
LICENSE LAMPS
LIFTGATE LOCK CYLINDER SWITCH
LT BLU WIRE
LT GRN WIRE
MASS AIR FLOW (MAF SENSOR)
NCA WIRE
NOT USED NOT USED
POWERTRAIN CONTROL MODULE (PCM)
REAR CONTROL UNIT (RCU)
REAR WINDOW DEFROST GRID
REAR WIPER MOTOR ASSEMBLY
RIGHT REAR LEFT TAIL LAMP TURN LAMP
RIGHT REAR SIDE LAMP
RIGHT REAR TURN LAMP RIGHT REAR SIDE LAMP
RIGHT REVERSING LAMP
RIGHT TAIL LAMP
SABLE
SABLE SABLE
SEDAN
TAURUS
TAURUS TAURUS
W/ SPOILER
WAGON
WHT WIRE
Go to component: -> Ground distribution circuit (3 of 3) -> LEFT LICENSE PLATE LAMP HIGH MOUNTED STOPLAMP
