Ford Taurus IV facelift (2004-2006) integrated control panel electronic compass wiring diagram
This page shows the only wiring diagram for the component.integrated control panel electronic compass, which is found in the car Ford Taurus IV facelift (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
integrated control panel electronic compass wiring diagram (1 of 1)
ACCES- SORY RELAY
ADJUSTABLE PEDAL SWITCH (EARLY PRODUCTION)
BATTERY JUNCTION BOX
BLK WIRE
DEACTIVATOR SWITCH BRAKE PEDAL POSITION SWITCH
DRIVER SIDE FRONT SEAT ADJUST SWITCH
EARLY PRODUCTION
FLEXIBLE FUEL SENSOR MODULE PASSIVE ANTI-THEFT TRANSCEIVER MODULE
FOG LAMP RELAY
FROM
FROM FUSE 3 (DIAGRAM 1 OF 3)
FRONT CIGAR LIGHTER
FUSE
FUSE 10
FUSE 16
FUSE 20
FUSE 32
FUSE 36
FUSE 7
FUSE FUSE
GRN WIRE
GRY WIRE
IGNITION SWITCH
INSTRUMENT CLUSTER
INTEGRATED CONTROL PANEL
INTEGRATED CONTROL PANEL ELECTRONIC COMPASS
LATE PRODUCTION
LOCK OFF
LOW CURRENT BOARD
LT BLU WIRE
LT GRN WIRE
LT GRN/VIO WIRE
LT LT
LT LT (LEFT SIDE OF DASH, BEHIND INSTRUMENT CLUSTER)
LT LT LT
MULTI- FUNCTION SWITCH
NCA WIRE
PASSENGER SIDE FRONT SEAT ADJUST SWITCH
PCM POWER RELAY
POWER POINT
REAR WINDOW DEFROST RELAY 1
RED WIRE
RELAY CENTER BOX 1 (LEFT FRONT OF ENGINE COMPARTMENT)
REMOTE CLIMATE CONTROL (RCC) MODULE
RESTRAINTS CONTROL MODULE SEAT WEIGHT SENSOR MODULE
RUN WIRE
SMART JUNCTION BOX (UNDER LEFT SIDE OF DASH)
TO FUSE 21 (SMART JUNCTION BOX) (DIAGRAM 3 OF 3)
TO FUSE 22 (SMART JUNCTION BOX) (DIAGRAM 3 OF 3)
TO FUSE 27 (SMART JUNCTION BOX) (DIAGRAM 3 OF 3)
VIO WIRE
VPWR
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 3) -> INTEGRATED CONTROL PANEL ELECTRONIC COMPASS
