Ford Taurus IV facelift (2004-2006) horn (lower left front of Wiring diagram
This page shows the only wiring diagram for the component.horn (lower left front of, which is found in the car Ford Taurus IV facelift (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram horn (lower left front of (1 of 1)
AIR BAG SLIDING CONTACT (NEAR BOTTOM OF STEERING COLUMN)
BLK WIRE
DK BLU WIRE
DK GRN/ORG WIRE
FUSE 38
HORN (LOWER LEFT FRONT OF
HORN RELAY
HOT AT ALL TIMES
LOW CURRENT BOARD
NCA WIRE
SMART JUNCTION BOX (UNDER LEFT SIDE OF DASH)
SPEED CONTROL SERVO (IN LEFT REAR OF ENGINE COMPARTMENT)
STEERING WHEEL/ SPEED CONTROL SWITCH
YEL/LT GRN WIRE
Go to component: -> Horn circuit -> HORN (LOWER LEFT FRONT OF
