Ford Taurus IV facelift (2004-2006) front up/down motor Wiring diagram

This page shows the only wiring diagram for the component.front up/down motor, which is found in the car Ford Taurus IV facelift (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram front up/down motor (1 of 1)

Wiring diagram front up/down motor for Ford Taurus IV facelift (2004-2006)

Get access

BLK WIRE CIRCUIT BREAKER 10 DRIVER SIDE FRONT SEAT ADJUST SWITCH ENTIRE SEAT FORWARD/ REARWARD MOTOR FRONT OF SEAT FRONT UP/DOWN MOTOR HOT AT ALL TIMES LEFT POWER SEAT MOTOR ASSEMBLY (UNDER DRIVER SEAT) LT BLU WIRE LT GRN WIRE NCA WIRE PASSENGER SIDE FRONT SEAT ADJUST SWITCH REAR OF SEAT REAR UP/DOWN MOTOR RED WIRE RIGHT POWER SEAT MOTOR ASSEMBLY SMART JUNCTION BOX (UNDER LEFT SIDE OF DASH) WHT WIRE YEL WIRE

Go to component: -> Power seats circuit -> FRONT UP/DOWN MOTOR
