Ford Taurus IV facelift (2004-2006) drv dr unlk rly door unlock rly door lock rly Wiring diagram

This page shows the only wiring diagram for the component.drv dr unlk rly door unlock rly door lock rly, which is found in the car Ford Taurus IV facelift (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram drv dr unlk rly door unlock rly door lock rly (1 of 1)

Wiring diagram drv dr unlk rly door unlock rly door lock rly for Ford Taurus IV facelift (2004-2006)

Get access

6 18 DOOR UNLOCK SW DOOR LOCK SW BLK WIRE DOOR LOCK RELAY DOOR UNLOCK RELAY DRIVER DOOR UNLOCK RELAY DRIVER SIDE DOOR LOCK SWITCH DRV DR UNLK RLY DOOR UNLOCK RLY DOOR LOCK RLY FUSE 26 GROUND HOT AT ALL TIMES LEFT FRONT DOOR LOCK ACTUATOR (REAR OF LEFT FRONT DOOR) LEFT REAR DOOR LOCK ACTUATOR (REAR OF LEFT REAR DOOR) LOCK LOW CURRENT BOARD LT BLU/BLK WIRE PASSENGER SIDE DOOR LOCK SWITCH PNK/BLK WIRE PNK/LT GRN WIRE PNK/ORG WIRE PNK/YEL WIRE RED/WHT WIRE RIGHT FRONT DOOR LOCK ACTUATOR (REAR OF RIGHT FRONT DOOR) RIGHT REAR DOOR LOCK ACTUATOR (RIGHT REAR DOOR) SMART JUNCTION BOX (CJB) (UNDER LEFT SIDE OF DASH) UNLOCK

Go to component: -> Power door locks circuit, without keyless entry -> DRV DR UNLK RLY DOOR UNLOCK RLY DOOR LOCK RLY
