Ford Taurus IV facelift (2004-2006) auto off Wiring diagram
This page shows the only wiring diagram for the component.auto off, which is found in the car Ford Taurus IV facelift (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram auto off (1 of 1)
AIR BAG SLIDING CONTACT (NEAR BOTTOM OF STEERING COLUMN)
AUTO OFF
BLK WIRE
BLK/LT BLU WIRE
BLK/ORG WIRE
BLK/PNK WIRE
BLK/YEL WIRE
BRN WIRE
BRN/LT BLU WIRE
COMPUTER DATA LINES SYSTEM
DOOR AJAR IND
FUSE 18 FUSE 33
FUSE 32 FUSE 22
GND MS CAN+ MS CAN- TONE GND
HOT AT ALL TIMES
HOT IN START OR RUN HOT IN RUN OR ACC
INSTRUMENT CLUSTER
KEY WARNING SWITCH
LEFT FRONT DOOR AJAR SWITCH (REAR OF LEFT FRONT DOOR)
LEFT SAFETY BELT ASSEMBLY
LOW CURRENT BOARD
LT BLU/PNK WIRE
LT GRN WIRE
MAIN LIGHT SWITCH
MICROPROCESSOR
MS CAN +
NCA WIRE
PARK HEAD
PNK WIRE
PNK/LT GRN WIRE
RED WIRE
RED/YEL WIRE
RESTRAINTS CONTROL MODULE (UNDER CENTER OF DASH)
SAFETY BELT BUCKLE SWITCH
SAFETY BELT IND
SMART JUNCTION BOX (UNDER LEFT SIDE OF DASH)
TONE
VBATT VPWR VPWR VREF
VREF
WHT WIRE
WHT/LT GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
Go to component: -> Warning systems circuit -> AUTO OFF
