Ford Taurus IV (1999-2004) Charging circuit

BATTERY BATTERY JUNCTION BOX (FRONT CENTER OF ENGINE COMPT) BLK WIRE CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH) CHARGE INDICATOR 390 OHMS FUSE 26 FUSE 27 GENERATOR GRY/YEL WIRE HOT IN START OR RUN INSTRUMENT CLUSTER LT BLU WIRE LT BLU/RED WIRE LT GRN WIRE MEGA FUSE NCA WIRE ORG/ WIRE POWER DISTRIBUTION SYSTEM POWERTRAIN CONTROL MODULE (PCM) (RIGHT REAR CORNER OF ENG COMPT) RED WIRE RED/YEL WIRE STARTER MOTOR WHT WIRE YEL WIRE
