Car Wiring Diagrams for Headlamps circuit, without drl for Ford Taurus IV (1999-2004)

BATTERY JUNCTION BOX BLK WIRE BLK/LT GRN WIRE BLK/YEL WIRE BRN WIRE CENTRAL JUNCTION BOX DK BLU WIRE DK GRN WIRE DK GRN/ORG WIRE FLASH TO PASS LO HI FOG LAMPS (NOT USED) FOG LAMPS ON IND FUSE 11 FUSE 16 FUSE 19 FUSE 21 FUSE 27 FUSE 29 GENERIC ELECTRONIC MODULE (UNDER LEFT SIDE OF DASH) GROUND HEAD HI LO HIGH BEAM IND HOT AT ALL TIMES HOT IN RUN OR ACC HOT IN RUN OR START INSTRUMENT CLUSTER LEFT FRONT FENDER) LEFT HEADLAMP LO HI LT GRN WIRE LT GRN/BLK WIRE MAIN LIGHT SWITCH MULTI- FUNCTION SWITCH (FLASH TO PASS) OFF ORG/ WIRE PARK OFF PARK OFF (NOT USED) AUTOLAMPS POWER, HOT W/ HIGH BEAMS ON RED WIRE RED/BLK WIRE RED/YEL WIRE RIGHT HEADLAMP VIO WIRE VIO/WHT WIRE WHT WIRE WHT/RED WIRE YEL WIRE
