Automatic a/c circuit for Ford Taurus IV (1999-2004)

A/C DEMAND SIG BLOWER RLY CTRL SENSOR SIGNAL RTN AMBIENT AIR TEMPERATURE SENSOR (BEHIND RIGHT SIDE OF FRONT BUMPER) BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLOWER MOTOR RELAY BRN WIRE CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH) DK BLU/LT GRN WIRE DK GRN/WHT WIRE DUAL PRESSURE SWITCH (BEHIND A/C COMPRESSOR) FRONT BLOWER MOTOR (RIGHT SIDE OF DASH, BELOW GLOVE BOX) FRONT BLOWER MOTOR SPEED CONTROLLER (BEHIND CENTER OF DASH, NEAR HVAC UNIT) FUSE 16 FUSE 28 FUSE 8 GENERIC ELECTRONIC MODULE (GEM) (UNDER LEFT SIDE OF DASH) HOT AT ALL TIMES HOT IN RUN IN-VEHICLE TEMPERATURE SENSOR INTEGRATED CONTROL PANEL (ICP) (BEHIND DASH, NEAR A/C-HEATER CONTROL UNIT) LT BLU/PNK WIRE ORG/ WIRE ORG/BLK WIRE PHOTO CELL, AMPIFIER (TOP RIGHT SIDE OF DASH) PNK WIRE PNK/ (BEHIND TOP CENTER OF INSTRUMENT CLUSTER) WIRE PNK/BLK WIRE PNK/LT BLU WIRE PNK/WHT WIRE RED WIRE RED/LT GRN WIRE RED/ORG WIRE RED/WHT WIRE RED/YEL WIRE SOLID STATE TAN WIRE TAN/ORG WIRE TEMPERATURE BLEND DOOR ACTUATOR (BEHIND INSTRUMENT CLUSTER, UNDER DASH PANEL) VIO WIRE VIO/ORG WIRE WHT WIRE WHT/ORG WIRE WHT/VIO WIRE YEL WIRE YEL/LT GRN WIRE

A/C CLUTCH DIODE A/C CLUTCH RELAY A/C CLUTCH SOLENOID BATTERY JUNCTION BOX (FRONT CENTER OF ENGINE COMPARTMENT, BEHIND RADIATOR) BLK WIRE BLK/YEL WIRE CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH) DATA LINK CONNECTOR (DLC) (PARTIAL) (MOUNTED ON DASH, BELOW STEERING COLUMN) DK BLU WIRE DK GRN/WHT WIRE ENGINE COOLANT TEMPERATURE (ECT) SENSOR (REAR OF ENGINE BLOCK, NEAR THERMOSTAT) ENGINE COOLING FAN BRAKE RELAY ENGINE COOLING FAN MOTOR 1 ENGINE COOLING FAN MOTOR 2 ENGINE COOLING FAN RELAY ENGINE COOLING FAN RESISTOR (NEAR COOLING FAN) EVAPORTATOR DISCHARGE AIR TEMPERATURE SENSOR) FUSE 22 FUSE 28 FUSE 9 GRY/RED WIRE HIGH SPEED FAN CONTROL RELAY HOT AT ALL TIMES HOT IN RUN OR START LOW SPEED FAN CONTROL RELAY LT BLU WIRE LT BLU/PNK WIRE LT GRN/RED WIRE LT GRN/VIO WIRE LT GRN/YEL WIRE ORG/ WIRE PCM POWER RELAY PNK WIRE PNK/LT BLU WIRE PNK/YEL WIRE REAR CONTROL UNIT (RCU) (IN LEFT SIDE OF LUGGAGE COMPARTMENT) RED WIRE RED/ORG WIRE TAN WIRE TAN/ORG WIRE
