Ford Taurus IV (1999-2004) liftgate ajar input wiring diagram
This page shows the only wiring diagram for the component.liftgate ajar input, which is found in the car Ford Taurus IV (1999-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
liftgate ajar input wiring diagram (1 of 1)
BLK WIRE
BLK/PNK WIRE
BRIGHT
CENTRAL JUNCTION BOX
DK GRN WIRE
DRIVER SIDE EXTERIOR REAR VIEW MIRROR
FROM BATTERY SAVER RELAY (CENTRAL JUNCTION BOX) (DIAGRAM 1 OF 2)
FROM INTERIOR LAMPS RELAY (DIAGRAM 1 OF 2)
FUSE 26
GENERIC ELECTRONIC MODULE (UNDER LEFT SIDE OF DASH)
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN
LEFT FRONT DOOR AJAR SWITCH
LEFT REAR DOOR AJAR SWITCH RIGHT REAR DOOR AJAR SWITCH
LEFT VANITY MIRROR LAMP
LF DOOR AJAR INPUT
LIFTGATE AJAR INPUT
LIFTGATE GLASS AJAR SWITCH (WAGON) LIFTGATE AJAR SWITCH (WAGON)
LR DOOR AJAR INPUT
LT BLU WIRE
LT GRN WIRE
LT GRN/ORG WIRE
LUGGAGE COMPARTMENT LAMP
LUGGAGE COMPT LID RELEASE SOLENOID
MIRROR OPEN
PASSENGER SIDE EXTERIOR REAR VIEW MIRROR
PNK WIRE
PUDDLE LAMP RELAY
RED WIRE
RF DOOR AJAR INPUT
RIGHT FRONT DOOR AJAR SWITCH
RIGHT VANITY MIRROR LAMP
RR DOOR AJAR INPUT
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> LIFTGATE AJAR INPUT
