Ford Taurus IV (1999-2004) left power/ heated mirror wiring diagram
This page shows the only wiring diagram for the component.left power/ heated mirror, which is found in the car Ford Taurus IV (1999-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
left power/ heated mirror wiring diagram (1 of 1)
AUTO A/C
BLK WIRE
CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH)
DK BLU WIRE
DK GRN WIRE
FUSE 11
FUSE 12
FUSE 27
FUSE 32
GENERIC ELEC- TRONIC MODULE (UNDER LEFT SIDE OF DASH)
HOT AT ALL TIMES
HOT IN
HOT IN RUN OR ACC
HOT IN START OR RUN
INTEGRATED CONTROL PANEL
LEFT FRONT FENDER)
LEFT POWER/ HEATED MIRROR
LT GRN WIRE
MANUAL A/C
ON INDICATOR
ORG/ WIRE
REAR WINDOW DEFROST FUSE 7
REAR WINDOW DEFROST GRID
REAR WINDOW DEFROST RELAY
REAR WINDOW DEFROST SWITCH
RIGHT POWER/ HEATED MIRROR
RUN WIRE
SOLID STATE
VIO WIRE
YEL WIRE
Go to component -> Defogger circuit -> LEFT POWER/ HEATED MIRROR
