Ford Taurus IV (1999-2004) a/c heater mode switch wiring diagram
This page shows the only wiring diagram for the component.a/c heater mode switch, which is found in the car Ford Taurus IV (1999-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
a/c heater mode switch wiring diagram (1 of 1)
A/C HEATER MODE SWITCH
BLK WIRE
BLOWER MOTOR (RIGHT SIDE OF DASH, BELOW GLOVE BOX)
BLOWER MOTOR RELAY
BLOWER SWITCH
BRN WIRE
CENTER JUNCTION BOX
FRONT BLOWER MOTOR RESISTOR ASSEMBLY (IN DASH, BELOW CENTER OF GLOVE BOX)
FUNCTION SELECTOR SWITCH ASSEMBLY (PART OF INTEGRATED CONTROL PANEL)
FUSE 28
FUSE 32
FUSE 8
GRN WIRE
HOT AT ALL TIMES
HOT IN RUN
LOW HIGH
LT GRN WIRE
LT LT
MED 2 MED 1
OFF FLOOR/VENT VENT FLOOR NORM MIX DEF MAX
OFF FLOOR/VENT VENT FLOOR NORM MIX MAX DEF
ORG/ WIRE
PNK WIRE
RED WIRE
RED/YEL WIRE
SOLID STATE
TEMPERATURE BLEND DOOR ACTUATOR
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Manual a/c circuit (1 of 2) -> A/C HEATER MODE SWITCH
