Ford Taurus IV (1999-2004) 4 6 batt gnd Wiring diagram

21 20 22 DOOR UNLOCK RLY DOOR LOCK RLY 4 6 BATT GND BLK WIRE BLK/LT GRN WIRE BLK/PNK WIRE CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH) DK BLU/YEL WIRE DOOR LOCK RELAY DOOR UNLOCK RELAY DRIVER DOOR UNLOCK RELAY DRIVER DOOR UNLOCK RLY DRIVER SIDE DOOR LOCK SWITCH FUSE 16 FUSE 22 GENERIC ELECTRONIC MODULE (GEM) (UNDER LEFT SIDE OF DASH) HOT AT ALL TIMES KEY PAD ILLUM KEYPAD IN KEYPAD SWITCH ASSEMBLY LEFT FRONT DOOR LOCK ACTUATOR LEFT FRONT FENDER) LEFT REAR DOOR LOCK ACTUATOR LIFT- GATE UNLOCK RELAY (WAGON) LIFTGATE LOCK ACTUATOR (WAGON) LIFTGATE OR TRUNK LID UNLOCK RLY CTRL DOOR UNLOCK SW DOOR LOCK SW 26 6 18 LOCK LT BLU WIRE LT BLU/BLK WIRE LT BLU/YEL WIRE LUGGAGE COMPART- MENT LID RELEASE RELAY (SEDAN) LUGGAGE COMPARTMENT LID RELEASE SOLENOID (SEDAN) ORG/LT GRN WIRE PASSENGER SIDE DOOR LOCK SWITCH PNK/BLK WIRE PNK/LT GRN WIRE PNK/ORG WIRE PNK/YEL WIRE RED WIRE RED/WHT WIRE RELAY CENTER BOX 2 (UNDER LEFT SIDE OF DASH) RIGHT FRONT DOOR LOCK ACTUATOR RIGHT REAR DOOR LOCK ACTUATOR SEDAN UNLOCK VIO/YEL WIRE WAGON WHT/RED WIRE YEL WIRE YEL/LT GRN WIRE
