Car Wiring Diagrams for Supplemental restraint circuit for Ford Taurus III (1995-1999)

* PIN SHORTING BAR IS ENGAGED WHEN MODULE CONNECTOR IS DISCONNECTED 10* 11* GND 2* DRVR AIR BAG 3* DRVR AIR BAG 4* 5* PASS AIR BAG AIR BAG DIAGNOSTIC MONITOR (FRONT CENTER OF I/P) AIR BAG IND AIR BAG INDICATOR BLK WIRE BLK/WHT WIRE BLK/YEL WIRE CLOCK SPRING ASSEMBLY DATA LINK DATA LINK CONNECTOR (BELOW LEFT SIDE OF I/P) DRIVER'S AIR BAG GRY WIRE GRY/ORG WIRE GRY/WHT WIRE HOT IN RUN I/P FUSE PANEL (LEFT SIDE OF I/P) HOT IN RUN OR START FUSE 13 FUSE 11 INSTRUMENT CLUSTER L CRASH SENS LT BLU WIRE LT BLU/ORG WIRE LT BLU/WHT WIRE LT GRN WIRE NCA WIRE ORG/ WIRE ORG/YEL WIRE PASS AIR BAG PASSENGER'S AIR BAG PNK PPL WIRE PNK/BLK WIRE PNK/WHT WIRE PPL/LT BLU WIRE PPL/ORG WIRE PWR (BAT) PWR RUN R CRASH SENS RIGHT RADIATOR PRIMARY CRASH SENSOR LEFT RADIATOR PRIMARY CRASH SENSOR SHORTING BAR TAN WIRE TAN/BLK WIRE WHT WIRE WHT/YEL WIRE YEL WIRE YEL/LT GRN WIRE YEL/WHT WIRE
