3.0l 24-valve, starting circuit for Ford Taurus III (1995-1999)

3.0l 24-valve, starting circuit

Get access

BATTERY BLK WIRE BRN/PNK WIRE CHARGING SYSTEM ENGINE COMPARTMENT FUSE , RELAY BOX FUSE 7 HOLD HOT AT ALL TIMES IGNITION FUSE 3 HOT IN START I/P FUSE PANEL LT GRN WIRE PNK WIRE PPL PULL- IN RED WIRE SENSOR (LEFT REAR OF ENG COMPT, ON TOP OF TRANSMISSION HOUSING) D/2 STARTER MOTOR SOLENOID STARTER RELAY (IN ENGINE COMPARTMENT FUSE/ RELAY BOX) TAN/RED WIRE TRANSMISSION RANGE (TR) WHT WIRE
