Lamp outage module circuit for Ford Taurus III (1995-1999)

Lamp outage module circuit

Get access

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 STOP LAMP IN 573 1046 102 (SEDAN ONLY) (SEDAN ONLY) BLK WIRE BLK/ORG WIRE FUSE 14 FUSE 31 GROUND HOT IN PARK OR HEAD HOT IN RUN I/P FUSE PANEL LAMP OUT WARNING MODULE (REAR LEFT SIDE OF CARGO AREA) LT GRN WIRE ORG/ WIRE RED/LT GRN WIRE RR PARK LPS IN RR PARK LPS OUT POWER (IGN) STOP LAMP OUT HI STOP LAMP IN HI STOP LAMP OUT RR PARK LPS IN RR PARK LPS OUT TAN WIRE WHT WIRE WHT/LT GRN WIRE
