Exterior lamps circuit, wagon with lamp out warning for Ford Taurus III (1995-1999)

AUTOLAMP PARK RELAY (IN ENG COMPT FUSE/RELAY BOX) BLK WIRE BLK/YEL WIRE BRN WIRE ELECTRONIC FLASHER (UNDER LEFT SIDE OF I/P) ENGINE COMPARTMENT FUSE/RELAY BOX FUSE 15 FUSE 29 HAZARD HEAD HEADLAMP SWITCH HOT AT ALL TIMES HOT IN RUN I/P FUSE PANEL INSTRUMENT CLUSTER LEFT LEFT FRONT MARKER LAMP LEFT FRONT PARK/ TURN LAMP LEFT LEFT FRONT FRONT PARK/ TURN TURN LAMP LAMP LEFT TURN IND LIGHT SENSOR/ AMPLIFIER (RIGHT SIDE OF I/P VENT, NEAR WINDSHIELD) LT BLU WIRE LT GRN/ORG WIRE LT GRN/WHT WIRE MULTI- FUNCTION SWITCH NORMAL OFF ORG/LT BLU WIRE PARK PARK LAMPS FUSE PPL/WHT WIRE RED/WHT WIRE RIGHT RIGHT FRONT MARKER LAMP RIGHT FRONT PARK/ TURN LAMP RIGHT FRONT TURN LAMP RIGHT TURN IND SABLE TAURUS WHT/LT BLU WIRE WHT/PPL WIRE WHT/RED WIRE

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 STOP LMP IN BLK WIRE BLK/ORG WIRE BRAKE ON/OFF (BOO) SWITCH (UPPER FRONT SIDE OF BRAKE PEDAL) BRN WIRE FUSE 28 FUSE 31 HOT AT ALL TIMES HOT IN RUN I/P FUSE PANEL FUSE 14 LAMP OUT WARNING MODULE (LEFT REAR SIDE OF CARGO AREA) LEFT HI MOUNT STOP LAMP LEFT REAR SIDE MARKER LAMP LEFT REAR TURN LAMP LICENSE LAMPS LEFT REAR PARK/ STOP LAMP LT GRN WIRE LT GRN/ORG WIRE LT GRN/RED WIRE NCA WIRE ORG/ WIRE ORG/LT BLU WIRE REAR PARK LMP IN REAR PARK LMP OUT PWR (ACC/RUN) RED/LT GRN WIRE RIGHT HI MOUNT STOP LAMP RIGHT REAR PARK/ STOP LAMP RIGHT REAR SIDE MARKER LAMP RIGHT REAR TURN LAMP STOP LMP OUT HMSL IN HMSL OUT TAN WIRE WHT/LT GRN WIRE
