Wiring diagram engine performance 3.0l 12-valves for Ford Taurus III (1995-1999)

AIR CONDITIONING SYSTEM (A/C HIGH PRESSURE SWITCH) BLK WIRE BLK/WHT WIRE BRN WIRE BRN/PNK WIRE CKP FEED CKP RTN CONSTANT CONTROL RELAY MODULE (ON LEFT SIDE OF BATTERY, BEHIND HEADLAMP) COOLING FANS SYSTEM (CONSTANT CONTROL RELAY MODULE) COOLING FANS SYSTEM (HEDF RELAY) CRANK- SHAFT POSITION SENSOR SHIELD DATA LINK CONNECTOR (BELOW STEERING COLUMN) DK BLU WIRE DK GRN WIRE DK GRN/ORG WIRE DK GRN/WHT WIRE DK GRN/YEL WIRE DLC BUS (-) DLC BUS (+) EAM AIR PUMP (LEFT FRONT OF VEHICLE, REAR OF BUMPER) EAM RLY EAM SOLID STATE RELAY (LEFT FRONT OF VEHICLE, REAR OF BUMPER) EEEC POWER FUSE EEEC RELAY ENGINE COMPARTMENT FUSE/RELAY BOX FUEL GAUGE DLC PPL FUEL PUMP FUSE FUEL PUMP RELAY GRY WIRE GRY/RED WIRE HEDF RLY CTRL EVR TACH HEGO POWER FUSE HORN FUSE HOT AT ALL TIMES HOT IN START OR RUN I/P FUSE PANEL (BELOW LEFT SIDE OF I/P) FUSE 10 IGNITION COIL INSTRUMENT CLUSTER INSTRUMENT CLUSTER SYSTEM (ANTI-SLOSH MODULE) KAPWR LEFT FRONT FENDER) LT BLU WIRE LT BLU/ORG WIRE LT GRN/PPL WIRE LT GRN/RED WIRE MAF RTN TFT ECT IAT FPM ACCS NCA WIRE OCT ADJ PSP OCTANE ADJUST PLUG (RIGHT REAR OF ENG COMPT, NEAR PCM) ORG/ WIRE ORG/BLK WIRE ORG/YEL WIRE PNK/BLK WIRE PNK/LT BLU WIRE PNK/LT GRN WIRE PNK/ORG WIRE PPL/ORG WIRE PWR GND GND IGN COIL A SS #1 EDF RLY CTRL PWR GND IGN COIL B SS #3 RED WIRE RED/BLK WIRE RED/YEL WIRE TACHO- METER CHECK ENGINE INDICATOR TAN/LT BLU WIRE TAN/ORG WIRE TAN/YEL WIRE THERMACTOR AIR BYPASS SOLENOID (ABOVE EXHAUST MANIFOLD, REAR OF ENG) THERMACTOR PUMP FUSE TO SPARK PLUGS WHT WIRE WHT/LT BLU WIRE WHT/ORG WIRE YEL WIRE YEL/BLK WIRE YEL/LT GRN WIRE YEL/RED WIRE YEL/WHT WIRE

BLK WIRE BLK/WHT WIRE BRN WIRE BRN/LT BLU WIRE BRN/PNK WIRE BRN/WHT WIRE BRN/YEL WIRE CAM- SHAFT POSITION SENSOR SHIELD DK BLU/ORG WIRE DK GRN/WHT WIRE DK GRN/YEL WIRE EGR VACUUM REGULATOR (EVR) VALVE (ON REAR OF INTAKE MANIFOLD) FUEL INJECTOR 1 FUEL INJECTOR 2 FUEL INJECTOR 3 FUEL INJECTOR 4 FUEL INJECTOR 5 FUEL INJECTOR 6 FUEL PRESSURE SENSOR (LEFT FRONT SIDE OF FUEL TANK) FUEL PUMP/ FUEL GAUGE SENDER (IN FUEL TANK) GRY WIRE GRY/BLK WIRE GRY/RED WIRE GRY/YEL WIRE INERTIA FUEL SHUT- OFF (IFS) SWITCH (BEHIND RIGHT WHEEL WELL) LT BLU/ORG WIRE LT BLU/RED WIRE LT GRN/ORG WIRE LT GRN/RED WIRE MASS AIR FLOW (MAF) SENSOR (NEAR AIR INTAKE ASSEMBLY) ORG/BLK WIRE ORG/YEL WIRE PNK/BLK WIRE PNK/ORG WIRE PPL/ORG WIRE PPL/WHT WIRE RED WIRE RED/BLK WIRE RED/YEL WIRE TAN WIRE TAN/BLK WIRE TAN/LT BLU WIRE VEHICLE SPEED SENSOR (VSS) (REAR CENTER OF ENG COMPT, ON TRANSAXLE) WHT WIRE WHT/LT BLU WIRE YEL/LT GRN WIRE YEL/WHT WIRE

AIR CONDI- TIONING SYSTEM AIR CONDITIONING SYSTEM BLK/WHT WIRE BLK/YEL WIRE BRAKE ON/OFF (BOO) SWITCH (ON BRAKE PEDAL) BRN WIRE BRN/LT BLU WIRE BRN/LT GRN WIRE BRN/WHT WIRE BRN/YEL WIRE DK BLU/ORG WIRE DK GRN/WHT WIRE ELECTRONIC PRESSURE CONTROL (EPC) SOLENOID EVAP CANP VALVE FPM EPC SOL TCC IAC TSS SENS CMP SENS A/C PRES FTP SENS FUEL INJ 5 FUEL INJ 3 FUEL INJ 1 PWR GND PWR GND IGN COIL C FUEL INJ 6 FUEL INJ 4 FUEL INJ 2 FUSE 12 GRY WIRE GRY/BLK WIRE GRY/LT BLU WIRE GRY/RED WIRE GRY/WHT WIRE GRY/YEL WIRE HEATED OXYGEN SENSOR #11 (BACK OF ENG) HEATED OXYGEN SENSOR #12 (LOWER LEFT SIDE OF ENG) HEATER CTRL HOT AT ALL TIMES HOT IN START OR RUN I/P FUSE PANEL (BELOW LEFT SIDE OF I/P) FUSE 28 INSTRUMENT CLUSTER SYSTEM INTAKE AIR TEMPERATURE SENSOR (ON AIR INTAKE ASSEMBLY) LEFT FRONT FENDER) LT BLU/ORG WIRE LT BLU/RED WIRE LT BLU/YEL WIRE LT GRN/ORG WIRE LT GRN/RED WIRE MAF SENS TP SENS REF VOLT SIG RTN BOO NCA WIRE ORG/BLK WIRE ORG/YEL WIRE PNK/BLK WIRE PNK/YEL WIRE PPL/LT GRN WIRE PPL/ORG WIRE PPL/WHT WIRE PPL/YEL WIRE PWR GND RED WIRE RED/BLK WIRE RED/LT GRN WIRE RED/PNK WIRE RED/WHT WIRE RED/YEL WIRE SHIFT SOLENOID 1 SHIFT SOLENOID 2 SHIFT SOLENOID 3 TAN WIRE TAN/BLK WIRE TAN/YEL WIRE TORQUE CONVERTER CLUTCH (TCC) SOLENOID TR SENS DPFE SENS TRANSAXLE (TOP CENTER OF TRANSAXLE) TRANSMISSION FLUID TEMPER- ATURE SENSOR TRANSMISSION RANGE SENSOR (TOP OF TRANSAXLE) VPWR VSS WAC RLY OUT EAM RELAY VPWR WHT WIRE WHT/BLK WIRE WHT/LT BLU WIRE WHT/YEL WIRE YEL/LT BLU WIRE YEL/WHT WIRE
