Ford Taurus III (1995-1999) Cruise control circuit

1 2 3 4 5 6 CRUISE ON IND 3.0L 2V OR 3.0L 4V 916 848 SPEED CONT SW IN SPEED CONT SW GND IGN ANTI-LOCK BRAKE CONTROL MODULE (BELOW BATTERY) BLK WIRE BLK/WHT WIRE BRAKE ON/OFF (BOO) SWITCH (UPPER FRONT SIDE OF BRAKE PEDAL) CLOCKSPRING ASSEMBLY (IN STEERING COLUMN, BELOW STEERING WHEEL) CRUISE ON IND DK BLU WIRE DK GRN WIRE DK GRN/ORG WIRE ELECTRIC CLTCH PWR GND ENGINE COMPART- MENT FUSE BOX FUSE 19 GRY/BLK WIRE HORN RELAY (IN ENGINE COMPT FUSE BOX) HORN SWITCHES HORN/ SPEED CONTROL HOT AT ALL TIMES HOT AT ALL TIMES FUSE 28 HOT IN RUN FUSE 6 HOT IN START OR RUN FUSE 12 I/P FUSE PANEL INSTRUMENT CLUSTER LEFT REAR PARK/ STOP LAMP LT BLU/BLK WIRE LT GRN WIRE LT GRN/RED WIRE NCA WIRE OFF ORG/ WIRE ORG/LT BLU WIRE PNK/ORG WIRE PPL/ORG WIRE RED WIRE RED/LT GRN WIRE RED/YEL WIRE REMOTE ANTI-THEFT PERSONALITY (RAP) MODULE (BEHIND INTEGRATED CONTROL PANEL) RESUME RIGHT HI MOUNT STOP LAMP LEFT HI MOUNT STOP LAMP RIGHT REAR PARK/ STOP LAMP SEDAN SEDAN ONLY SET/ COAST ACCEL SPEED CONTROL DEACTIVATE SWITCH (LEFT SIDE OF I/P) SPEED CONTROL MODULE (MOUNTED ON LEFT FRONT STRUT) TAN/ORG WIRE VEHICLE SPEED INPUT BRAKE APPLIED IN VEHICLE SPEED SENSOR (VSS) (ON TRANSAXLE) W/ RAP
