Rear camera circuit, customer access for Ford RV Cutaway E350 Super Duty (1999-2011)

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 VPWR REVERSE GND 1 2 3 4 5 6 VPWR VIDEO SHLD AUDIO CONTROL MODULE (ACM) BLK WIRE BLK/GRY WIRE BLU WIRE BLU/WHT WIRE BRN WIRE BRN/YEL WIRE CUSTOMER ACCESS CONNECTOR (LEFT "B" PILLAR) FUSE HOT W/ ACCESSORY DELAY RELAY ENERGIZED NCA WIRE REAR VIEW CAMERA (CENTER OF RIGHT REAR DOOR) VIDEO+ VIDEO+ VIDEO- GND YEL/GRY WIRE
