Courtesy lamps circuit, except cutaway without entertainment system for Ford RV Cutaway E350 Super Duty (1999-2011)

7 20 INT LPS OUT INT LPS OUT 8 21 22 23 26 GROUND GROUND BATTERY GROUND BLK WIRE BLK/LT BLU WIRE BLK/WHT WIRE BRN WIRE CENTRAL JUNCTION BOX LEFT SIDE OF DASH, NEAR KICK PANEL) DRIVER SIDE EXTERIOR REAR VIEW MIRROR ENDS IN HARNESS EXCEPT RV VAN FRONT INTERIOR/ MAP LAMPS ASSEMBLY FUSE 2 FUSE 4 FUSE 5 HIGH MOUNTED STOPLAMP HINGED SIDE DOOR HOT AT ALL TIMES HOT IN START OR RUN INTERIOR LEFT FRONT DOOR AJAR SWITCH LEFT VANITY MIRROR LAMP LT BLU WIRE LT GRN WIRE LT GRN/YEL WIRE MAIN LIGHT SWITCH NCA WIRE PASSENGER SIDE EXTERIOR REAR VIEW MIRROR PNK WIRE PUDDLE LAMP RELAY (BOTTOM OF LEFT "B" PILLAR) REAR DOORS AJAR SWITCH RED WIRE REMOTE KEYLESS ENTRY MODULE (BEHIND LEFT "B" PILLAR) RIGHT FRONT DOOR AJAR SWITCH RIGHT SIDE DOOR AJAR SWITCH RIGHT SLIDING DOOR AJAR SWITCH RIGHT VANITY MIRROR LAMP RV VAN SIDE DOOR CTSY SW SLIDING SIDE DOOR W/ FULL HEADLINER W/ REMOTE KEYLESS ENTRY W/O FULL HEADLINER W/O REMOTE KEYLESS ENTRY WARNING SYSTEM WHT WIRE YEL WIRE

BLK WIRE BLK/LT BLU WIRE CARGO LAMP FROM FRONT INTERIOR/ MAP LAMPS ASSEMBLY HIGH MOUNTED STOPLAMP INTERIOR LAMP LEFT VANITY MIRROR LAMP LT BLU WIRE LT GRN WIRE LT GRN/YEL WIRE NCA WIRE REAR DOORS AJAR SWITCH REAR INTERIOR LAMP RIGHT VANITY MIRROR LAMP YEL WIRE
