Anti-lock brakes circuit, without stripped chassis for Ford RV Cutaway E350 Super Duty (1999-2011)

1 2 3 4 5 6 7 8 9 10 11 DATA LINK CONN BPP SWITCH INPUT ABS CONTROL MODULE (AT LEFT SIDE OF ENGINE COMPT) ABS IND. BATTERY JUNCTION BLK WIRE BOX (BJB) (AT LEFT SIDE OF ENGINE COMPARTMENT) BRAKE FLUID LEVEL SWITCH (AT LEFT REAR OF ENGINE COMPT) BRAKE PEDAL POSITION SWITCH (ON BRACKET ABOVE BRAKE PEDAL) CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) DATA LINK CONNECTOR (DLC) (BELOW LEFT SIDE OF DASH) DIESEL EXCEPT DIESEL DK GRN WIRE FUSE 1 FUSE 11 FUSE 14 GRN WIRE GROUND VBATT GROUND VBATT BRAKE IND CTRL HOT AT ALL TIMES HOT IN RUN HOT IN RUN OR START INSTRUMENT CLUSTER LEFT FRONT SENSOR (LOW) RIGHT FRONT SENSOR (LOW) REAR SENSOR (LOW) LEFT FRONT WHEEL SPEED SENSOR (BEHIND LEFT FRONT WHEEL) LOW BRAKE FLUID LEVEL/ PARK BRAKE IND LT BLU WIRE LT BLU/PNK WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/YEL WIRE MICROPROCESSOR NCA WIRE ORG/YEL WIRE PNK WIRE RED WIRE RED/PNK WIRE RIGHT FRONT WHEEL SPEED SENSOR (BEHIND RIGHT FRONT WHEEL) TAN WIRE TAN/BLK WIRE TAN/LT GRN WIRE TAN/ORG WIRE WHT WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE
