Ford Ranger T6.2 (2022-2024) windshield washer fluid level switch Wiring diagram
This page shows the only wiring diagram for the component.windshield washer fluid level switch, which is found in the car Ford Ranger T6.2 (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram windshield washer fluid level switch (1 of 1)
AAT
AJAR
AMBIENT AIR TEMPERATURE (AAT) SENSOR
ANTI-LOCK BRAKES SYSTEM
BATTERY JUNCTION BOX (BJB)
BLK/GRY WIRE
BLK/VIO WIRE
BLU WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRK FLUID
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DIRECT CURRENT/ DIRECT CURRENT (DC/DC) CONVERTER CONTROL MODULE
ENGINE CONTROLS SYSTEM
ENGINE OIL PRESSURE (EOP) SENSOR
EOP
FUEL PUMP, SENDER UNIT
FUEL SENDER 1
FUEL SENDER 1 RTN
FUSE 13
FUSE 2
FUSE 23
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
GRY/RED WIRE
GRY/VIO WIRE
HEAD-UP DISPLAY (HUD) MODULE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HILL DESCENT
HOT AT ALL TIMES
HOT W/ RUN/START RELAY ENERGIZED
IGN OUT
INSTRUMENT PANEL CLUSTER (IPC)
LF DOOR
LOGIC GND
LOW WASHER
LR DOOR
MICRO -
NCA WIRE
PARK BRAKE
PARK DETECT
POWERTRAIN CONTROL MODULE (PCM)
RED WIRE
RF DOOR
RR DOOR
SHIFT INTERLOCK SYSTEM
SIG RTN
TCS ON/OFF
VBATT
VPWR
VREF
WHT WIRE
WHT/GRN WIRE
WHT/VIO WIRE
WINDSHIELD WASHER FLUID LEVEL SWITCH
YEL WIRE
YEL/VIO WIRE
Go to component -> Instrument cluster circuit (1 of 2) -> WINDSHIELD WASHER FLUID LEVEL SWITCH
