Ford Ranger T6.2 (2022-2024) right front door release ambient lamp Wiring diagrams
This page contains all the electrical diagrams for the component. right front door release ambient lamp, in which he is found in the car Ford Ranger T6.2 (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right front door release ambient lamp (1 of 2)
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLU WIRE
BLU/GRY WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/WHT WIRE
CARGO
CARGO LAMP SWITCH
CLOSED OPEN
COMPUTER DATA LINES SYSTEM
CREW CAB
FRONT BIN AMBIENT LAMP
GRN WIRE
GRN/RED WIRE
GRN/VIO WIRE
INSTRUMENT ILLUMINATION CIRCUIT
LEFT FRONT DOOR LATCH
LEFT FRONT DOOR RELEASE AMBIENT LAMP
LEFT FRONT FOOTWELL LAMP
LEFT REAR DOOR AJAR SWITCH
LEFT REAR DOOR LATCH
LF DOOR AJAR
LIN 13
LIN 15
LOGIC GND
LR DOOR AJAR
MICRO -
OPEN CLOSED
PWR
RF DOOR AJAR
RIGHT FRONT DOOR LATCH
RIGHT FRONT DOOR RELEASE AMBIENT LAMP
RIGHT FRONT FOOTWELL LAMP
RIGHT REAR DOOR AJAR SWITCH
RIGHT REAR DOOR LATCH
RR DOOR AJAR
SUPER CAB
VIO/GRY WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> RIGHT FRONT DOOR RELEASE AMBIENT LAMP
Wiring diagram right front door release ambient lamp (2 of 2)
ANTI-LOCK BRAKE SYSTEM (ABS) MODULE
BATTERY ENERGY CONTROL MODULE B (BECMB)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLOWER MOTOR RELAY
CLOCKSPRING
DIRECT CURRENT/ ALTERNATING CURRENT (DC/AC) INVERTER
EXTERIOR MIRROR CONTROL SWITCH
GATEWAY MODULE A (GWM)
GLOVE COMPARTMENT LAMP
GRY WIRE
HAZARD SWITCH
HORN SWITCH
LEFT STEERING WHEEL SWITCH
LEFT VANITY MIRROR LAMP
NCA WIRE
OVERHEAD CONSOLE
POWER STEERING CONTROL MODULE (PSCM)
REAR INTERIOR LAMP
RIGHT EXTERIOR MIRROR
RIGHT FRONT DOOR LOCK SWITCH
RIGHT FRONT DOOR RELEASE AMBIENT LAMP
RIGHT STEERING WHEEL SWITCH
RIGHT VANITY MIRROR LAMP
TRAILER TOW BACKUP LAMP RELAY
TRANSMISSION RELAY
UPFITTER RELAY 1
UPFITTER RELAY 2
UPFITTER RELAY 3
UPFITTER RELAY 4
UPFITTER RELAY 5
UPFITTER RELAY 6
VIO WIRE
W/ AMBIENT LIGHTING
W/O SYNC
WINDSHIELD WASHER PUMP
WINDSHIELD WIPER MOTOR
Go to component -> Ground distribution circuit (4 of 5) -> RIGHT FRONT DOOR RELEASE AMBIENT LAMP
