Ford Ranger T6.2 (2022-2024) lamps on Wiring diagram
This page shows the only wiring diagram for the component.lamps on, which is found in the car Ford Ranger T6.2 (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lamps on (1 of 1)
AUTOLAMP
AUTOLAMP ON
AUTOLAMP SENSOR
AUTOLAMP/SUNLOAD SENSOR (TOP CENTER OF DASH)
AUTOMATIC A/C
BATTERY JUNCTION BOX (BJB)
BLK/GRY WIRE
BLU WIRE
BLU/BRN WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM)
BRN/BLU WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
DIM +
DRV SUNLOAD
FRONT CONTROLS INTERFACE MODULE (FCIM)
FRONT FOG
FRONT FOG SWITCH
FUSE 13
FUSE 62
FUSE 67
GRN/ORG WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/RED WIRE
GRY/VIO WIRE
H/L ON
HEAD/PARK
HEADLAMP SWITCH
HOT AT ALL TIMES
ILLUM
LAMPS OFF
LAMPS ON
LOW BEAM REQ
MANUAL A/C
MICRO -
MS CAN +
MULTI- FUNCTION SWITCH
OFF
PARK
PARK BRK
PARKING BRAKE WARNING INDICATOR SWITCH
PASS SUNLOAD
RTN
STEERING COLUMN CONTROL MODULE (SCCM)
VBATT
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
WHT WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLU WIRE
YEL/VIO WIRE
